3-195-C Kelford Camshaft 3SGTE

3-195-C Kelford Camshaft Celica GT4 ST205 3SGTE 307/300 Duration, 12.25mm/10.65mm Lift. All Motor drag race or lightweight race car cams, 12.5/1 and close ratio gearbox. 3-195-C The Kelford Cams range of camshafts suits the generation 3 Toyota 3S-GE and 3S-GTE engines, produced from 1994 to 1999. These engines have the tappet shim on top of the valve tip so can benefit from higher lift cam profiles compared to the Gen 2 engines. Kelford can also manufacture cams to your specifications, or design a profile to suit your specific application.

Engine Make:		Engine Model:				Part Number:
TOYOTA		3S-GE (Gen 3)				3-195-C
Valve Clearance:		Intake:	0.25mm	Set	COLD	at the	CAM
		Exhaust:	0.30mm	Set	COLD	at the	CAM
Cam Lift:		Intake:			12.50mm	Exhaust:	10.95mm
Rocker Ratio:		Intake:			1	Exhaust:	1
Nett Valve Lift:		Intake:			12.25mm	Exhaust:	10.65mm
Advertised Duration @	0.30mm	Intake:			307	Exhaust:	300
Duration @	1.00mm VALVE LIFT	Intake:			273	Exhaust:	261
Timing @	1.00mm VALVE LIFT	IVO:			38.5 BTDC	EVO:	52.5 BBDC
		IVC:			54.5 ABDC	EVC:	28.5 ATDC
Suggested Centre Lines:		Intake:			98	Exhaust:	102
VALVE	Lift @ TDC	Intake:			5.12mm	Exhaust:	4.50
